MECHANICAL FABRICATION SECTION
The main function of this section is to fabricate different types of engineering items for project & research works of B.Tech, M.Tech and Ph. D. students. This Section caters the service to almost all the departments of the Institute for any type of precision and complicated mechanical fabrication or repair work.
Surface Grinder Machine
MAKE: ALEX
Maximum Working Area-
Material to be cut-
Aluminium (thickness -1")
Mild steel (thickness - 3mm)
Copper (thickness - 1")
Brass (thickness - 1")
Power Saw (CONV.)
ITL KASTO
Material can be cut: stainless steel, aluminium, Mild steel,
copper, brass.
Cutting Range: - 240X240mm (900), 280X160mm (900)
Dia. 160mm (900).
LB-17 LATHE
MAKE: HMT
The length between centres : 8 Feet
Centre Height: 220 mm
Swing over the Bed: 340 mm
Length between centre: 800 mm
The maximum stock bar diameter: 45 mm No. of spindle speed: 8
MODEL: H22 LATHE
MAKE: HMT
The length between centres : 8 Feet
Centre Height: 220 mm
Swing over the Bed: 340 mm
Length between centre: 800 mm
The maximum stock bar diameter: 45 mm No. of spindle speed: 8
Vertical Milling Machine
MAKE: CINCINNATI
Pedestal Grinder Machine
CONVENTIONAL
Material to be grind -
HSS, MS, SS etc.
TL 200V2 (CONVENTIONAL)
Band Saw
Material to be cut-
Aluminium (thickness -1")
Mild steel (thickness - 3mm)
Copper (thickness - 1")
Brass (thickness - 1")
2 BENCH DRILLING MACHINE
CONVENTIONAL
Material to be cut-
Aluminium (thickness -1")
Mild steel (thickness - 3mm)
Copper (thickness - 1")
Brass (thickness - 1")
Muffle Furnace With PID Temperature Controller
Bench Drilling Machine
Vertical Milling Machine
MAKE: HMT
Horizontal Milling Machine
MAKE: HMT
Universal Milling machine
MAKE: CINCINNATI
SEMI - AUTOMATIC HORIZONTAL BAND SAW MACHINE
Band Dimension:
6300(L) MM X 54(W) MM X 1.3 (Thick) MM.
Cutting Capacity:
Round Solid - 600 MM
Round Hollow - 600 MM
Square / Flat - 600 MM X 600 MM
Hex Section - 600 MM
Material cutting by saw : Al, SS – 304,316 and other High Carbon Steel, etc.
Driving Engine Capacity: 15 HP
